واحد:mm
| کد |
Thread |
قطر سوراخ نصب
|
D2 |
B1 |
L1 |
L2 |
L3 |
سایز کابل
|
بسته بندی
|
| AG-12 |
M12xP1.25 |
12.0 |
8.3 |
6.9 |
7.9 |
19.6 |
13.6 |
3 ~ 6.5 |
50 تعداد در بسته
|
| AG-12L |
M12xP1.5 |
12.0 |
8.3 |
6.9 |
7.9 |
19.6 |
13.6 |
3 ~ 6.5 |
| AG-16 |
M16xP1.5 |
16.0 |
10.9 |
10.5 |
15.5 |
23.4 |
16.9 |
5 ~ 10 |
| AG-16S |
M16xP1.5 |
16.0 |
10.9 |
10.5 |
10.0 |
23.4 |
16.9 |
5 ~ 10 |
| AG-20 |
M20xP1.5 |
20.0 |
15.0 |
14.0 |
15.0 |
28.5 |
18.5 |
10 ~ 14 |
| AG-20S |
M20xP1.5 |
20.0 |
15.0 |
14.0 |
10.0 |
28.5 |
18.5 |
10 ~ 14 |
| AG-25 |
M25xP1.5 |
25.0 |
18.6 |
18.4 |
15.2 |
29.4 |
22.3 |
13 ~ 18 |
| AG-25S |
M25xP1.5 |
25.0 |
18.6 |
18.4 |
10.0 |
29.4 |
22.3 |
13 ~ 18 |
| AG-32 |
M32xP1.5 |
32.0 |
26.0 |
25.0 |
14.7 |
34.5 |
25.7 |
18 ~ 25 |
25تعداد در بسته |
| AG-40 |
M40xP1.5 |
40.0 |
33.7 |
33.0 |
18.4 |
41.7 |
31.3 |
22 ~ 32 |
10 تعداد در بسته |
| AG-50 |
M50xP1.5 |
50.0 |
41.9 |
40.0 |
17.8 |
44.2 |
31.3 |
30 ~ 38 |
| AG-63 |
M61xP1.5 |
61.0 |
55.0 |
44.0 |
18.5 |
44.6 |
32.7 |
34 ~ 44 |
| AG-63M |
M63xP1.5 |
63.0 |
54.9 |
44.0 |
18.5 |
44.6 |
32.7 |
34 ~ 44 |
| AG-63L |
M63xP1.5 |
63.0 |
56.6 |
51.5 |
25.4 |
49.0 |
36.8 |
42 ~ 50 |
کد
|
Thread |
قطر سوراخ نصب
|
D2 |
B1 |
L1 |
L2 |
L3 |
سایز کابل
|
بسته بندی
|
| AG-12D |
M12xP1.25 |
12.0 |
7.3 |
6.5 |
8.0 |
19.7 |
12.7 |
3 ~ 6.5 |
50تعداد در بسته
|
| AG-16D |
M16xP1.5 |
16.0 |
10.7 |
10.1 |
8.0 |
23.3 |
16.1 |
5 ~ 10 |
| AG-20D |
M20xP1.5 |
20.0 |
14.1 |
12.4 |
10.0 |
25.0 |
18.1 |
8 ~ 12 |
| AG-25D |
M25xP1.5 |
25.0 |
18.0 |
17.1 |
8.0 |
30.0 |
20.0 |
11 ~ 17 |
| AG-32D |
M32xP1.5 |
32.0 |
25.7 |
21.2 |
10.0 |
35.4 |
24.1 |
15 ~ 21 |
25تعداد در بسته |
| AG-40D |
M40xP1.5 |
40.0 |
32.7 |
28.2 |
10.0 |
39.4 |
27.5 |
20 ~ 28 |
10 تعداد در بسته |
| AG-50D |
M50xP1.5 |
50.0 |
42.2 |
35.3 |
12.0 |
43.4 |
31.6 |
27 ~ 35 |
| AG-63D |
M63xP1.5 |
63.0 |
55.0 |
42.4 |
12.0 |
46.4 |
33.7 |
32 ~ 42 |
|
